YOUXIN Plastic Machinery is an excellent plastic shredder Chinese manufacturer. Our waste plastic shredder is renowned in the waste plastic recycling industry for its superior performance and excellent quality. And the waste plastic thick wall pipe shredder is one of our hot sale product which is helpful is large diameter plastic pipe recycling, this machine can shredder the long and thick-walled pipe directly and with no difficulty.
What is a Waste Plastic Thick Wall Pipe Shredder?
Waste Plastic Thick Wall Pipe Shredder is one of the waste plastic shredder which is designed specially for large, thick-walled and long plastic pipes, this machine is very popular in waste plastic pipe recycling industry because of its practical, convenient, energy-saving, and efficient. All the machines are Made of high quality carbon steel and using class technology, and are widely attributes like efficient and consistent performance, lower power consumption, durability and corrosion resistance.
| Waste Plastic Thick Wall Pipe Shredder | |
| Model | 800 |
| Motor Power | 37KW*2sets |
| Hydraulic motor | 11KW |
| Qty of rotating blades | 96PCS |
| Qty of fixed blades | 4PCS |
| Shaft Length | 800mm |
| Hydraulic effect distance | 3000mm |
The plastic pipe shredder has strong structure,which is made by quality carbon steel.
The plastic pipe shredder has unique design shaft ,which can shred the large diameter pipe directly.
The plastic pipe shredder fitted high quality blades made by D2, which is hardly to wear.
A long hydraulic pusher is equipped on the plastic pipe shredder ,so the machine can shred 3 meters long pipe without cutting.
Adopts pure copper wire motor ,which is powerful and durable.
Using hard gear side box to reduce the speed of the shaft and increase the torque.
The waste plastic thick wall pipe shredder is ideally suited for reducing a wide range of different materials:
Large diameter HDPE pipe, thick wall PPR pipe, plastic sewage pipe, heavy plastic lumps, large plastic blocks, huge plastic containers, plastic profile, thicken plastic plate, thick wall-ed plastic sheets.
Waste plastic thick wall pipe shredder is useful in waste plastic recycling process.
01 Electronic cabinet
The electrical components adopt known brands DELIXI, with high configuration and operation.
02 Gearbox
Using hard gear side reduce with high torque.
03 Hydraulic slider
The hydraulic ram can push the material against the rotor,speed can be adjusted.
04 Hydraulic pump
Oil cylinder effective is fitted with water cooling device.
05 Rotary Shaft
Unique designed rotary shaft made by high quality carbon steel,anti-worn.
We have advanced CNC machine center,testing equipment, and professional technician team to ensure the quality of our Plastic crusher.
OEM and ODM are available.
In order to better give you professional answers, when sending the inquiry, please describe your parameters or technical requirements (such as: processing materials, output size, capacity, etc.) and attach your contact information (such as phone number, e-mail, Facebook, WhatsApp , WeChat, etc.)
