YOUXIN Plastic Machinery is deeply in designing and manufacturing high quality single shaft plastic lump shredders with brilliant function and easy to use. The single shaft shredder fitted High-efficient and Energy-saving Motor, durable and high torque gear reducer, can shred a wide range of waste plastics, like blocks, pipes and plastic lumps,plastic thick sheet, plastic board, plastic die materials, plastic head materials, various used cables, wood, waste paper and electronic waste etc.
What is a Plastic Single Shaft Plastic Lump Shredder?
Plastic Single Shaft Plastic Lump Shredder is a versatile machine suitable for recycling operations in production of valuable secondary raw materials. By adjusting the rotor speed and screen size, the final discharge size can be controlled and is suitable for the treatment of municipal solid waste, the production of fuel derived from waste, etc.
| Single Shaft Plastic Lump Shredder | |
| Model | 800 |
| Motor Power | 37KW |
| Hydraulic motor | 5.5KW |
| Qty of rotating blades | 48PCS |
| Qty of fixed blades | 4PCS |
| Shaft Length | 800mm |
| Effective hydraulic distance | 800mm |
The motor drives the cutter shaft to drive the high torque rotation of the cutter, the material entering the shredding chamber is pushed by the feeder to the middle of the movable cutter shaft and the fixed cutters, the cutters on the shaft and the fixed cutters cooperate to shear and tear the material for shredding, the unqualified material is brought back to the shredding area by the cutters for further shredding, the material reaching the size of the discharge falls from the screen to achieve the purpose of shredding.
Plastic Single Shaft Plastic Lump Shredder has advantages such as efficient processing of various materials, versatility in handling different types of materials, and environmental benefits through easier recycling and waste management.
Different feeding hopper can be designed according to customer's requirements. Standard feeding hopper is suitable to feed large quantities and big blocks of material. This kind of hopper can make optimal production. The mechanical pusher push material to rotor continuously, so the output is high. Automatic shredding process can not make it stuck.
The Plastic Single Shaft Plastic Lump Shredder is a shredding equipment with a wide range of applications. It is designed to meet the waste recycling requirements of various industries. It can be used in a wide variety of materials, including various plastic products such as blocks, pipes and plastic lumps,plastic thick sheet, plastic board, plastic die materials, plastic head materials, various used cables, wood, waste paper and electronic waste etc. The size of the shredded material depends on the features of material and the next step, and the shredded material can be directly recycled or for being further crushed.
01 Pure copper motor
Power surging,Strong power comes from a good motor,Durable,Worry-free quality, long-lasting.
02 Electronic cabinet
Controlled by PLC control system; the blade can reverse automatically to protect the machine when overload.
03 Gearbox
The gearbox of the shredder is welded with steel plates, with high accuracy, good contact, low noise, and long service life.
04 Screen
Mesh size can be designed according to customer requirement ,Mesh can control the size of the material.
05 Hydraulic pump
Oil cylinder effective working Pushing speed is adjusted by manual
The Hydraulic ram pressure and timing can be adjusted to fit with different material. The machine be fitted with water cooling device.
06 Shaft
The use of high strength heavy duty special steel processing refined, more reasonable with the tool to provide powerful power for cutting.
07 Shredding chamber
We have advanced CNC machine center,testing equipment, and professional technician team to ensure the quality of our Plastic crusher.
OEM and ODM are available.
